Part Number 71307000

Highlights

Premium optical system with reference beam
Automatic test recognition with internal barcode reader
Automatic cuvette type detection
Support of analytical quality assurance

The XD series instruments are ideal for routine and spectral analysis. As true all-rounders, the XD 7000 and XD 7500 facilitate work routines, especially with automatic method recognition using barcodes, automatic cell recognition and more than 150 pre-programmed methods. In addition to analytical quality control, they also support Good Labor Practice (GLP). The instruments are available together with bar-coded test tubes and a wide range of accessories from a single source – which is also easy on your wallet. High-quality reference beam optics, usability, easy handling and multilingual global applicability round off the versatility of the VIS and UV/VIS spectrophotometers, which are also equipped for flexible on-site use.

Categories: Lab & Portable Instruments, Lovibond, Water Testing Products, XD Spectrophotometers Tags: Lab & Portable Instruments lovibond Spectrophotometer XD 7000 (VIS) XD Spectrophotometers

Latest technology
The XD 7000 and XD 7500 spectrophotometers are equipped with VIS respectively UV / VIS reference beam technology.
Automatic test recognition
Each of the more than 150 pre-programmed Lovibond^® methods is recognized by barcode as well as the cuvette type.
Analytical quality assurance
Standard procedures for analytical quality assurance support the verification of the photometer, the overall system (including the chemical methodology) and the verification of matrix effects.
Built-in security levels
The devices support the assignment of passwords and the assignment of up to three different levels of rights.
Additional functions
Measurement of transmission and absorption, spectral scan, kinetics analysis, as well as the creation of user-defined methods.
Interfaces for data processing
You want to process your data? With Ethernet, USB B, USB A for external memory, keyboard, barcode scanner and printer different versions are available.

Technical Data

Optics	Grid monochromator with reference beam and beam splitter after exit slit
Measurement	Concentration, single and multi-wavelength measurement of absorbance and % transmission, kinetics, spectra
Wavelength Range	320 – 1100 nm
Wavelength Resolution	1 nm
Wavelength Accuracy	± 1 nm on all Holmium peaks
Wavelength Reproducibility	better than 0,5 nm
Spectral Scope	4 nm
Photometric Range	-3.3 – +3.3 Abs
Photometric Resolution	Absorption: 0.001 ; Transmission: 0.1 %
Photometric Accuracy	0.003 Abs below 0.6 Abs ; 0.5 % from 0.6 to 2.0 Abs
Photometric Reproducability	0.003 Abs below 0.6 Abs ; 0.5 % from 0.6 to 2.0 Abs
Photometric Linearity	< 1 % up to 2.0 Abs between 340 to 900 nm
Scan Speed	700 – 2000 nm/min.
Drift	< 0.005 Abs per hour after 15 minutes heat up time
Operation	Membrane Keyboard
Display	7“ high contrast colour graphic-display
Suitable Vials	Rectangular Cuvettes 10 mm Rectangular Cuvettes 20 mm Rectangular Cuvettes 50 mm Round Cuvettes 13 mm Round Cuvettes 16 mm Round Cuvettes 24 mm
Automatic Cuvette Recognition	Round cuvettes: 13, 16 and 24 mm ; Rectangular cuvettes: 10, 20 and 50mm
Test Recognition	via internal barcode reader
Interfaces	Ethernet USB B USB A for External Memory Keypad Barcode-Scanner PCL Compatible Printer
Stray Light	< 0.1 % Transmission at 340 and 408 nm
Auto-Check	Self-test at each switch-on: test of memory, processor, internal interface, filter lamp and additional calibration of each wavelength
LIMS Compatibility	ASCII, .csv-files
Internal Storage	approx. 5000 data sets (method, user ID, date, result), autostorage function / manual storage function
Security	Password protection possible: 3 different user levels (guest, user, admin)
Power Drain	100 – 240 V, 50/60 Hz
Power Supply	Buffer batteries (4 x AA), power supply unit with cable
Auto – OFF	Yes
Portability	Benchtop
Environmental Conditions	+10 °C to 35 °C (41 °F to 95 °F), ≤ 75 % average humidity within one year 95 %, max. 30 days/year, 85 % all other days
Stock Conditions	-25 °C to +65 °C (-13 °F to 268 °F)
Compliance	CE
Protection Class	IP 30
IP Protection Class	EN 60529
Interference Emission	Class B
Interference Immunity	IEC 61000-4-3
Tolerance Extension	0.008 E
Meter Safety	EC Directive 2014/35/EC EN 61010-1:2010
Languages User Interface	German, English, French, Spanish, Italian, Portuguese, Polish, Indonesian, Russian, Chinese, Japanese, Dutch, Swedish, Norwegian, Czech, Romanian, Macedonian, Slovenian, Hungarian, Turkish, Korean, Vietnamese, Thai, Serbian, Malaysian, Danish, Bulgarian
Languages Quick Start Guide	German, English, French, Spanish, Italian, Portuguese, Polish, Indonesian, Russian, Chinese, Japanese, Dutch, Swedish, Norwegian, Czech, Romanian, Macedonian, Slovenian, Hungarian, Turkish, Korean, Vietnamese, Thai, Serbian, Malaysian, Danish, Bulgarian
Languages Full User Manual	German, English, Spanish, French, Italian, Portuguese, Chinese, Japanese
Dimensions	422 x 195 x 323 mm
Weight	4.5 kg

Range

Testparameter	Measuring Range	Method No.	Chemical Method
Alkalinity-m HR T	5 – 500 mg/L CaCO₃	M31	Acid / Indicator
Alkalinity-m T	5 – 200 mg/L CaCO₃	M30	Acid / Indicator
Alkalinity-p T	5 – 500 mg/L CaCO₃	M35	Acid / Indicator
Aluminium PP	0.01 – 0.25 mg/L Al	M50	Eriochrom Cyanine R
Aluminium T	0.01 – 0.3 mg/L Al	M40	Eriochrom Cyanine R
Ammonia HR TT	1.0 – 50 mg/L N	M66	Salicylate
Ammonia LR TT	0.02 – 2.5 mg/L N	M65	Salicylate
Ammonia PP	0.01 – 0.8 mg/L N	M62	Salicylate
Ammonia T	0.02 – 1 mg/L N	M60	Indophenole Blue
Arsenic	0.02 – 0.6 mg/L As	M68	Silver Diethyldithiocarbamate
Boron T	0.1 – 2 mg/L B	M85	Azomethine
Bromine 10 T	0.1 – 3 mg/L Br₂	M78	DPD
Bromine 50 T	0.05 – 1 mg/L Br₂	M79	DPD
Bromine PP	0.05 – 4.5 mg/L Br₂	M81	DPD
Bromine T	0.05 – 13 mg/L Br₂	M80	DPD
Cadmium M. TT	0.025 – 0.75 mg/L Cd	M87	Cadion
Chloride L (A)	5.00 – 60 mg/L Cl^–	M91	Iron(III)-thiocyanate
Chloride L (B)	0.5 – 20 mg/L Cl^–	M92	Mercury Thiocyanate / Iron Nitrate
Chloride T	0.5 – 25 mg/L Cl^–	M90	Silver Nitrate / Turbidity
Chlorine 10 T	0.1 – 6 mg/L Cl₂	M98	DPD
Chlorine 50 T	0.02 – 0.5 mg/L Cl₂	M99	DPD
Chlorine dioxide 50 T	0.05 – 1 mg/l ClO₂	M119	DPD / Glycine
Chlorine dioxide PP	0.04 – 3.8 mg/l ClO₂	M122	DPD
Chlorine dioxide T	0.02 – 11 mg/l ClO₂	M120	DPD / Glycine
Chlorine HR 10 T	0.1 – 10 mg/L Cl₂	M104	DPD
Chlorine HR (KI) T (105)	5 – 200 mg/L Cl₂	M105	KI / Acid
Chlorine L	0.02 – 4.0 mg/L Cl₂	M101	DPD
Chlorine MR PP	0.02 – 3.5 mg/L Cl₂	M113	DPD
Chlorine PP	0.02 – 2 mg/L Cl₂	M110	DPD
Chlorine T	0.01 – 6.0 mg/L Cl₂	M100	DPD
Chromium 50 PP	0.005 – 0.5 mg/L Cr	M124	Diphenylcarbazide
Chromium PP	0.02 – 2 mg/L Cr	M125	Diphenylcarbazide
COD HR TT	200 – 15000 mg/L COD	M132	Dichromate / H₂SO₄
COD LMR TT	15 – 300 mg/L COD	M133	Dichromate / H₂SO₄
COD LR TT	3 – 150 mg/L COD	M130	Dichromate / H₂SO₄
COD MR TT	20 – 1500 mg/L COD	M131	Dichromate / H₂SO₄
COD VLR TT	2.0 – 60.0 mg/L COD	M134	Dichromate / H₂SO₄
Copper 50 T	0.05 – 1 mg/L Cu	M149	Biquinoline
Copper L	0.05 – 4 mg/L Cu	M151	Bicinchoninate
Copper PP	0.05 – 5 mg/L Cu	M153	Bicinchoninate
Copper T	0.05 – 5 mg/L Cu	M150	Biquinoline
Cyanide 50 L	0.005 – 0.2 mg/L CN^–	M156	Pyridine-barbituric Acid
Cyanide L	0.01 – 0.5 mg/L CN^–	M157	Pyridine-barbituric Acid
CyA T	10 – 160 mg/L CyA	M160	Melamine
DEHA PP	0.02 – 0.5 mg/L DEHA	M167	PPST
DEHA T (L)	0.02 – 0.5 mg/L DEHA	M165	PPST
Fluoride L	0.05 – 2 mg/L F^–	M170	SPADNS
Formaldehyde 10 M. L	1.00 – 5.00 mg/L HCHO	M175	H₂SO₄ / Chromotropic acid
Formaldehyde 50 M. L	0.02 – 1.00 mg/L HCHO	M176	H₂SO₄ / Chromotropic acid
Formaldehyde M. TT	0.1 – 5 mg/L HCHO	M177	H₂SO₄ / Chromotropic acid
H₂O₂ 50 T	0.01 – 0.5 mg/L H₂O₂	M209	DPD / Catalyst
H₂O₂ HR L	40 – 500 mg/L H₂O₂	M214	Titanium Tetrachloride / Acid
H₂O₂ LR L	1 – 50 mg/L H₂O₂	M213	Titanium Tetrachloride / Acid
H₂O₂ T	0.03 – 3 mg/L H₂O₂	M210	DPD / Catalyst
Hardness Calcium (B) T	20 – 500 mg/L CaCO₃	M191	Murexide
Hardness Calcium (B) T	50 – 900 mg/L CaCO₃	M190	Murexide
Hardness total HR T	20 – 500 mg/L CaCO₃	M201	Metallphthaleine
Hardness total T	2 – 50 mg/L CaCO₃	M200	Metallphthaleine
Hazen 24	10 – 500 mg/L Pt	M204	(APHA) Platinum Cobalt Standard Method
Hazen 50	10 – 500 mg/L Pt	M203	(APHA) Platinum Cobalt Standard Method
Hydrazine C	0.01 – 0.7 mg/L N₂H₄	M207	PDMAB
Hydrazine L	5 – 600 µg/L N₂H₄	M206	Dimethylaminobenzaldehyde
Hydrazine P	0.05 – 0.5 mg/L N₂H₄	M205	Dimethylaminobenzaldehyde
Hypochlorite T	0.2 – 17 % NaOCl	M212	Potassium Iodide
Iron 10 T	0.05 – 1 mg/L Fe	M218	Ferrozine / Thioglycolate
Iron 50 PP	0.01 – 1.5 mg/L Fe	M221	1,10-Phenanthroline
Iron 50 T	0.01 – 0.5 mg/L Fe	M219	Ferrozine / Thioglycolate
Iron (TPTZ) PP	0.02 – 1.8 mg/L Fe	M223	TPTZ
Iron HR L	0.1 – 10 mg/L Fe	M227	Thioglycolate
Iron in Mo PP (224)	0.01 – 1.8 mg/L Fe	M224	TPTZ
Iron LR L (A)	0.03 – 2 mg/L Fe	M225	Ferrozine / Thioglycolate
Iron LR L (B)	0.03 – 2 mg/L Fe	M226	Ferrozine / Thioglycolate
Iron PP	0.02 – 3 mg/L Fe	M222	1,10-Phenanthroline
Iron T	0.02 – 1 mg/L Fe	M220	Ferrozine / Thioglycolate
K_S4.3 T	0.1 – 4 mmol/L K_S4.3	M20	Acid / Indicator
Lead 10	0.1 – 5 mg/L Pb	M232	4-(2-Pyridylazo-)-resorcine
Lead (A) TT	0.1 – 5 mg/L Pb	M234	4-(2-Pyridylazo-)-resorcine
Lead (B) TT	0.1 – 5 mg/L Pb	M235	4-(2-Pyridylazo-)-resorcine
lodine T	0.05 – 3.6 mg/L I	M215	DPD
Manganese HR PP	0.1 – 18 mg/L Mn	M243	Periodate Oxidation
Manganese L	0.05 – 5 mg/L Mn	M245	Formaldoxime
Manganese LR PP	0.01 – 0.7 mg/L Mn	M242	PAN
Manganese T	0.2 – 4 mg/L Mn	M240	Formaldoxime
Molybdate HR L	1 – 100 mg/L MoO₄	M254	Thioglycolate
Molybdate HR PP	0.3 – 40 mg/L Mo	M252	Mercaptoacetic Acid
Molybdate LR PP	0.03 – 3 mg/L Mo	M251	Ternary Complex
Molybdate T	1 – 50 mg/L MoO₄	M250	Thioglycolate
Nickel 50 L	0.02 – 1 mg/L Ni	M255	Dimethylglyoxime
Nickel L	0.2 – 7 mg/L Ni	M256	Dimethylglyoxime
Nitrate HR	1.2 – 35 mg/L N	M268	2,6-Dimethylphenole
Nitrate LR2 TT	0.2 – 15 mg/L N	M266	2,6-Dimethylphenole
Nitrate LR TT	0.5 – 14 mg/L N	M267	2,6-Dimethylphenole
Nitrate T	0.08 – 1 mg/L N	M260	Zinc Reduction / NED
Nitrate TT	1 – 30 mg/L N	M265	Chromotropic Acid
Nitrite HR PP	2 – 250 mg/L NO₂ ^–	M273	Ferrous Sulfate Method
Nitrite HR TT	0.3 – 3 mg/L N	M276	Sulfanilic / Naphthylamine
Nitrite LR TT	0.03 – 0.6 mg/L N	M275	Sulfanilic / Naphthylamine
Nitrite PP	0.01 – 0.3 mg/L N	M272	Diazotation
Nitrite T	0.01 – 0.5 mg/L N	M270	N-(1-Naphthyl)-ethylendiamine
Nitrite VHR L	25 – 2500 mg/L NO₂ ^–	M271	Ferrous Sulfate Method
Oxygen active T	0.1 – 10 mg/L O₂	M290	DPD
Oxygen dissolved C	10 – 1100 µg/L O₂	M292	Rhodazine D TM
Ozone 50 T	0.02 – 0.5 mg/L O₃	M299	DPD / Glycine
Ozone PP	0.015 – 2 mg/L O₃	M301	DPD / Glycine
Ozone T	0.02 – 2 mg/L O₃	M300	DPD / Glycine
Phenol T	0.1 – 5 mg/L C₆H₅OH	M315	4-Aminoantipyrine
PHMB T	2 – 60 mg/lLPHMB	M70	Buffer / Indicator
Phosphate h. TT	0.02 – 1.6 mg/L P	M325	Phosphomolybdenum Blue
Phosphate HR C	1.6 – 13 mg/L P	M327	Vanadomolybdate
Phosphate HR L	5 – 80 mg/L PO₄	M335	Vanadomolybdate
Phosphate HR T	0.33 – 26.09 mg/L P	M321	Vanadomolybdate
Phosphate HR TT	0.98 – 19.57 mg/L P	M322	Vanadomolybdate
Phosphate LR C	0.016 – 1.6 mg/L P	M328	Stannous Chloride
Phosphate LR L	0.1 – 10 mg/L PO₄	M334	Phosphomolybic Acid / Ascorbic Acid
Phosphate LR T	0.016 – 1.305 mg/L P	M320	Phosphomolybdenum Blue
Phosphate PP	0.02 – 0.815 mg/L P	M323	Phosphomolybdenum Blue
Phosphate t. TT	0.02 – 1.1 mg/L P	M326	Phosphomolybdenum Blue
Phosphate total HR TT	1.5 – 20 mg/L P	M318	Phosphomolybdenum Blue
Phosphate total LR TT	0.07 – 3 mg/L P	M317	Phosphomolybdenum Blue
Phosphate TT	0.02 – 1.63 mg/L P	M324	Phosphomolybdenum Blue
Phosphonate PP	0.02 – 125 mg/L PO₄	M316	Persulfate UV Oxidation Method
pH-value HR T	8.0 – 9.6 pH	M332	Thymol Blue
pH value L	6.5 – 8.4 pH	M331	Phenol Red
pH-value LR T	5.2 – 6.8 pH	M329	Bromocresolpurple
pH-value T	6.5 – 8.4 pH	M330	Phenol Red
Polyacrylate L	1 – 30 mg/L Polyacryl	M338	Turbidity
Potassium T	0.7 – 16 mg/L K	M340	Tetraphenylborat Turbidity
SAC 436 nm	0.5 – 50 m^-1	M345	Direct Reading EN ISO 7887:1994
SAC 525 nm	0.5 – 50 m^-1	M346	Direct Reading EN ISO 7887:1994
SAC 620 nm	0.5 – 50 m^-1	M347	Direct Reading EN ISO 7887:1994
Selenium	0.05 – 2 mg/L Se	M363	3,3′-Diaminobenzidine in Toluene
Silcate T	0.05 – 4 mg/L SiO₂	M350	Silicomolybdenum Blue
Silicate HR PP	1 – 100 mg/L SiO₂	M352	Silicomolybdate
Silicate L	0.1 – 8 mg/L SiO₂	M353	Heteropolyblue
Silicate LR PP	0.05 – 1.6 mg/L SiO₂	M351	Heteropolyblue
Silica VLR PP	0.005 – 0.5 mg/L SiO₂	M349	Heteropolyblue
Sulphate HR PP	50 – 1000	M361	Bariumsulphate Turbidity
Sulphate PP	5 – 100 mg/L SO₄ ^2-	M360	Bariumsulphate Turbidity
Sulphate T	5 – 100 mg/L SO₄ ^2-	M355	Bariumsulphate Turbidity
Sulphide T	0.04 – 0.5 mg/L S^2-	M365	DPD / Catalyst
Sulphite 10 T	0.1 – 12 mg/L SO₃	M368	DTNB
Sulphite T	0.1 – 5 mg/L SO₃	M370	DTNB
Surfactants M. (anion.) TT	0.05 – 2 mg/L SDSA	M376	Methylene Blue
Surfactants M. (cation.) TT	0.05 – 1.5 mg/L CTAB	M378	Disulphine Blue
Surfactants M. (not ionic) TT	0.1 – 7.5 mg/L Triton X-100	M377	TBPE
Suspended solids 24	10 – 750 mg/L TSS	M384	Turbidity / Attenuated Radiation Method
Suspended solids 50	10 – 750 mg/L TSS	M383	Turbidity / Attenuated Radiation Method
TN HR 2 TT	5 – 140 mg/L N	M284	2,6-Dimethylphenole
TN HR TT	5 – 150 mg/L N	M281	Persulphate Digestion
TN LR 2 TT	0.5 – 14 mg/L N	M283	2,6-Dimethylphenole
TN LR TT	0.5 – 25 mg/L N	M280	Persulphate Digestion
TOC HR M. TT	50 – 800 mg/L TOC	M381	H₂SO₄ / Persulphate / Indicator
TOC LR M. TT	5 – 80 mg/L TOC	M380	H₂SO₄ / Persulphate / Indicator
Triazole PP	1 – 16 mg/L Benzotriazole or Tolyltriazole	M388	Catalyzed UV Digestion
Turbidity 24	10 – 1000 FAU	M386	Attenuated Radiation Method
Turbidity 50	5 – 500 FAU	M385	Attenuated Radiation Method
Urea T	0.1 – 2.5 mg/L Urea	M390	Indophenol / Urease
Zinc L	0.1 – 2.5 mg/L Zn	M405	Zincon / EDTA
Zinc T	0.02 – 1 mg/L Zn	M400	Zincon

Suitable Reagents

Title	Measuring Range	Chemical Method	Packaging Unit	Part Number
Alka-M-Photometer	5 – 200 mg/L CaCO₃	Acid / Indicator	Tablet / 100	513210BT
Alka-M-Photometer	5 – 200 mg/L CaCO₃	Acid / Indicator	Tablet / 250	513211BT
Alka-M-HR Photometer	5 – 500 mg/L CaCO₃	Acid / Indicator	Tablet / 100	513240BT
Alka-M-HR Photometer	5 – 500 mg/L CaCO₃	Acid / Indicator	Tablet / 250	513241BT
Alka-P-Photometer	5 – 500 mg/L CaCO₃	Acid / Indicator	Tablet / 100	513230BT
Alka-P-Photometer	5 – 500 mg/L CaCO₃	Acid / Indicator	Tablet / 250	513231BT
Aluminium No. 1	0.01 – 0.3 mg/L Al	Eriochrom Cyanine R	Tablet / 100	515460BT
Aluminium No. 1	0.01 – 0.3 mg/L Al	Eriochrom Cyanine R	Tablet / 250	515461BT
Aluminium No. 2	0.01 – 0.3 mg/L Al	Eriochrom Cyanine R	Tablet / 100	515470BT
Aluminium No. 2	0.01 – 0.3 mg/L Al	Eriochrom Cyanine R	Tablet / 250	515471BT
Set Aluminium No. 1/No. 2 100 Pc.	0.01 – 0.3 mg/L Al	Eriochrom Cyanine R	100 each	517601BT
Set Aluminium No. 1/No. 2 250 Pc.	0.01 – 0.3 mg/L Al	Eriochrom Cyanine R	250 each	517602BT
VARIO Aluminium Reagent, Set F20	0.01 – 0.25 mg/L Al	Eriochrom Cyanine R	1 pc.	535000
Ammonia No. 1	0.02 – 1 mg/L N	Indophenole Blue	Tablet / 100	512580BT
Ammonia No. 1	0.02 – 1 mg/L N	Indophenole Blue	Tablet / 250	512581BT
Ammonia No. 2	0.02 – 1 mg/L N	Indophenole Blue	Tablet / 100	512590BT
Ammonia No. 2	0.02 – 1 mg/L N	Indophenole Blue	Tablet / 250	512591BT
Set Ammonia No. 1/No. 2 100 Pc.	0.02 – 1 mg/L N	Indophenole Blue	100 each	517611BT
Set Ammonia No. 1/No. 2 250 Pc.	0.02 – 1 mg/L N	Indophenole Blue	250 each	517612BT
Ammonia Conditioning Powder	0.02 – 1 mg/L N	Indophenole Blue	Powder / 26 g	460170
VARIO Ammonia Nitrogen, Set F10	0.01 – 0.8 mg/L N	Salicylate	1 Set	535500
VARIO Am Vial Test Reagent, Set Low Rage F5	0.02 – 2.5 mg/L N	Salicylate	1 Set	535600
VARIO am Vial Test Reagent Set High Range F5	1.0 – 50 mg/L N	Salicylate	1 Set	535650
PHMB Photometer	2 – 60 mg/lLPHMB	Buffer / Indicator	Tablet / 100	516100BT
PHMB Photometer	2 – 60 mg/lLPHMB	Buffer / Indicator	Tablet / 250	516101BT
DPD No. 1	0.1 – 3 mg/L Br₂	DPD	Tablet / 100	511050BT
DPD No. 1	0.1 – 3 mg/L Br₂	DPD	Tablet / 250	511051BT
DPD No. 1	0.1 – 3 mg/L Br₂	DPD	Tablet / 500	511052BT
DPD No. 1 High Calcium	0.1 – 3 mg/L Br₂	DPD	Tablet / 100	515740BT
DPD No. 1 High Calcium	0.1 – 3 mg/L Br₂	DPD	Tablet / 250	515741BT
DPD No. 1 High Calcium	0.1 – 3 mg/L Br₂	DPD	Tablet / 500	515742BT
Chlorine Total DPD F10	0.05 – 4.5 mg/L Br₂	DPD	Powder / 100 pc.	530120
Cadmium Spectroquant 1.14834.0001 tube test	0.025 – 0.75 mg/L Cd	Cadion	25 pc.	420750
Chloride T1	0.5 – 25 mg/L Cl^–	Silver Nitrate / Turbidity	Tablet / 100	515910BT
Chloride T1	0.5 – 25 mg/L Cl^–	Silver Nitrate / Turbidity	Tablet / 250	515911BT
Chloride T2	0.5 – 25 mg/L Cl^–	Silver Nitrate / Turbidity	Tablet / 100	515920BT
Chloride T2	0.5 – 25 mg/L Cl^–	Silver Nitrate / Turbidity	Tablet / 250	515921BT
Set Chloride T1/T2 100 Pc.	0.5 – 25 mg/L Cl^–	Silver Nitrate / Turbidity	100 each	517741BT
Set Chloride T1/T2 250 Pc.	0.5 – 25 mg/L Cl^–	Silver Nitrate / Turbidity	250 each	517742BT
Chloride Reagent Test	5.00 – 60 mg/L Cl^–	Iron(III)-thiocyanate	1 pc.	2419031
Chlorid Reagent Set	0.5 – 20 mg/L Cl^–	Mercury Thiocyanate / Iron Nitrate	1 pc.	56R018490
DPD No. 3	0.1 – 6 mg/L Cl₂	DPD	Tablet / 100	511080BT
DPD No. 3	0.1 – 6 mg/L Cl₂	DPD	Tablet / 250	511081BT
DPD No. 3	0.1 – 6 mg/L Cl₂	DPD	Tablet / 500	511082BT
DPD No. 3 High Calcium	0.1 – 6 mg/L Cl₂	DPD	Tablet / 100	515730BT
DPD No. 3 High Calcium	0.1 – 6 mg/L Cl₂	DPD	Tablet / 250	515731BT
DPD No. 3 High Calcium	0.1 – 6 mg/L Cl₂	DPD	Tablet / 500	515732BT
DPD No. 4	0.1 – 6 mg/L Cl₂	DPD	Tablet / 100	511220BT
DPD No. 4	0.1 – 6 mg/L Cl₂	DPD	Tablet / 250	511221BT
DPD No. 4	0.1 – 6 mg/L Cl₂	DPD	Tablet / 500	511222BT
DPD No. 3 EVO	0.1 – 6 mg/L Cl₂	DPD	Tablet / 100	511420BT
DPD No. 3 EVO	0.1 – 6 mg/L Cl₂	DPD	Tablet / 250	511421BT
DPD No. 3 EVO	0.1 – 6 mg/L Cl₂	DPD	Tablet / 500	511422BT
DPD No. 4 EVO	0.1 – 6 mg/L Cl₂	DPD	Tablet / 100	511970BT
DPD No. 4 EVO	0.1 – 6 mg/L Cl₂	DPD	Tablet / 250	511971BT
DPD No. 4 EVO	0.1 – 6 mg/L Cl₂	DPD	Tablet / 500	511972BT
DPD 1 Buffer Solution, Blue Bottle	0.02 – 4.0 mg/L Cl₂ ^a)	DPD	15 mL	471010
DPD 1 Buffer Solution	0.02 – 4.0 mg/L Cl₂ ^a)	DPD	100 mL	471011
DPD 1 Buffer Solution	0.02 – 4.0 mg/L Cl₂ ^a)	DPD	1 pc.	471016
DPD 1 Reagent Solution, Green Bottle	0.02 – 4.0 mg/L Cl₂ ^a)	DPD	15 mL	471020
DPD 1 Reagent Solution	0.02 – 4.0 mg/L Cl₂ ^a)	DPD	100 mL	471021
DPD 1 Reagent Solution	0.02 – 4.0 mg/L Cl₂ ^a)	DPD	1 pc.	471026
DPD 3 Solution, Red Bottle	0.02 – 4.0 mg/L Cl₂ ^a)	DPD	15 mL	471030
DPD 3 Solution	0.02 – 4.0 mg/L Cl₂ ^a)	DPD	100 mL	471031
DPD 3 Solution	0.02 – 4.0 mg/L Cl₂ ^a)	DPD	1 pc.	471036
DPD Reagent Set	0.02 – 4.0 mg/L Cl₂ ^a)	DPD	1 pc.	471056
DPD No. 1 HR	0.1 – 10 mg/L Cl₂ ^a)	DPD	Tablet / 100	511500BT
DPD No. 1 HR	0.1 – 10 mg/L Cl₂ ^a)	DPD	Tablet / 250	511501BT
DPD No. 1 HR	0.1 – 10 mg/L Cl₂ ^a)	DPD	Tablet / 500	511502BT
DPD No. 3 HR	0.1 – 10 mg/L Cl₂ ^a)	DPD	Tablet / 100	511590BT
DPD No. 3 HR	0.1 – 10 mg/L Cl₂ ^a)	DPD	Tablet / 250	511591BT
DPD No. 3 HR	0.1 – 10 mg/L Cl₂ ^a)	DPD	Tablet / 500	511592BT
Set DPD No. 1 HR/No. 3 HR 100 Pc.	0.1 – 10 mg/L Cl₂ ^a)	DPD	100 each	517791BT
Set DPD No. 1 HR/No. 3 HR 250 Pc.	0.1 – 10 mg/L Cl₂ ^a)	DPD	250 each	517792BT
DPD No. 3 HR EVO	0.1 – 10 mg/L Cl₂ ^a)	DPD	Tablet / 100	511920BT
DPD No. 3 HR EVO	0.1 – 10 mg/L Cl₂ ^a)	DPD	Tablet / 250	511921BT
DPD No. 3 HR EVO	0.1 – 10 mg/L Cl₂ ^a)	DPD	Tablet / 500	511922BT
Chlorine HR (KI)	5 – 200 mg/L Cl₂	KI / Acid	Tablet / 100	513000BT
Chlorine HR (KI)	5 – 200 mg/L Cl₂	KI / Acid	Tablet / 250	513001BT
Acidifying GP	5 – 200 mg/L Cl₂	KI / Acid	Tablet / 100	515480BT
Acidifying GP	5 – 200 mg/L Cl₂	KI / Acid	Tablet / 250	515481BT
Set Chlorine HR (KI)/Acidifying GP 100 Pc.	5 – 200 mg/L Cl₂	KI / Acid	100 each	517721BT
Set Chlorine HR (KI)/Acidifying GP 250 Pc.	5 – 200 mg/L Cl₂	KI / Acid	250 each	517722BT
Chlorine HR (KI)	5 – 200 mg/L Cl₂	KI / Acid	Tablet / 100	501210
Chlorine HR (KI)	5 – 200 mg/L Cl₂	KI / Acid	Tablet / 250	501211
Chlorine Free DPD F10	0.02 – 2 mg/L Cl₂ ^a)	DPD	Powder / 100 pc.	530100
Chlorine Free DPD F10	0.02 – 2 mg/L Cl₂ ^a)	DPD	Powder / 1000 pc.	530103
Chlorine Total DPD F10	0.02 – 2 mg/L Cl₂ ^a)	DPD	Powder / 1000 pc.	530123
VARIO Chlorine Free DPD F10	0.02 – 3.5 mg/L Cl₂ ^a)	DPD	Powder / 100 pc.	530180
VARIO Chlorine Free DPD F10	0.02 – 3.5 mg/L Cl₂ ^a)	DPD	Powder / 1000 pc.	530183
VARIO Chlorine Total DPD F10	0.02 – 3.5 mg/L Cl₂ ^a)	DPD	Powder / 100 pc.	530190
VARIO Chlorine Total DPD F10	0.02 – 3.5 mg/L Cl₂ ^a)	DPD	Powder / 1000 pc.	530193
Set DPD No. 1/No. 3 100 Pc.	0.05 – 1 mg/l ClO₂	DPD / Glycine	100 each	517711BT
Set DPD No. 1/No. 3 250 Pc.	0.05 – 1 mg/l ClO₂	DPD / Glycine	250 each	517712BT
Set DPD No. 1/Glycine 100 Stck.	0.05 – 1 mg/l ClO₂	DPD / Glycine	100 each	517731BT
Set DPD No. 1/Glycine 250 Stck.	0.05 – 1 mg/l ClO₂	DPD / Glycine	250 each	517732BT
Set DPD No. 1/No. 3 High Calcium 100 Pc.	0.05 – 1 mg/l ClO₂	DPD / Glycine	100 each	517781BT
Set DPD No. 1/No. 3 High Calcium 250 Pc.	0.05 – 1 mg/l ClO₂	DPD / Glycine	250 each	517782BT
Glycine	0.05 – 1 mg/l ClO₂	DPD / Glycine	Tablet / 100	512170BT
Glycine	0.05 – 1 mg/l ClO₂	DPD / Glycine	Tablet / 250	512171BT
VARIO Glycine Reagent 10 %, 29 ml	0.04 – 3.8 mg/l ClO₂	DPD	29 mL	532210
Persulfat Reagent für CR	0.005 – 0.5 mg/L Cr^b)	Diphenylcarbazide	Powder / 100 pc.	537300
Chromium Hexavalent	0.005 – 0.5 mg/L Cr^b)	Diphenylcarbazide	Powder / 100 pc.	537310
COD LR/25	3 – 150 mg/L COD^b)	Dichromate / H₂SO₄	25 pc.	2420720
COD LR/25, mercury free	3 – 150 mg/L COD^b)	Dichromate / H₂SO₄	25 pc.	2420710
COD LR/150	3 – 150 mg/L COD^b)	Dichromate / H₂SO₄	150 pc.	2420725
COD MR/25	20 – 1500 mg/L COD^b)	Dichromate / H₂SO₄	25 pc.	2420721
COD MR/25, mercury free	20 – 1500 mg/L COD^b)	Dichromate / H₂SO₄	25 pc.	2420711
COD MR/150	20 – 1500 mg/L COD^b)	Dichromate / H₂SO₄	150 pc.	2420726
COD MR/150, mercury free	20 – 1500 mg/L COD^b)	Dichromate / H₂SO₄	150 pc.	2420716
COD HR/25	200 – 15000 mg/L COD^b)	Dichromate / H₂SO₄	25 pc.	2420722
COD HR/25, mercury free	200 – 15000 mg/L COD^b)	Dichromate / H₂SO₄	25 pc.	2420712
COD HR/150	200 – 15000 mg/L COD^b)	Dichromate / H₂SO₄	150 pc.	2420727
COD LMR	15 – 300 mg/L COD^b)	Dichromate / H₂SO₄	25 pc.	2423120
COD VLR/25	2.0 – 60.0 mg/L COD^b)	Dichromate / H₂SO₄	25 pc.	2423100
Copper No. 1	0.05 – 1 mg/L Cu^a)	Biquinoline	Tablet / 100	513550BT
Copper No. 1	0.05 – 1 mg/L Cu^a)	Biquinoline	Tablet / 250	513551BT
Copper No. 2	0.05 – 1 mg/L Cu^a)	Biquinoline	Tablet / 100	513560BT
Copper No. 2	0.05 – 1 mg/L Cu^a)	Biquinoline	Tablet / 250	513561BT
Set Copper No. 1/No. 2 100 Pc.	0.05 – 1 mg/L Cu^a)	Biquinoline	100 each	517691BT
Set Copper No. 1/No. 2 250 Pc.	0.05 – 1 mg/L Cu^a)	Biquinoline	250 each	517692BT
Copper Reagent Set	0.05 – 4 mg/L Cu^a)	Bicinchoninate	1 pc.	56R023355
VARIO CU1 F10	0.05 – 5 mg/L Cu	Bicinchoninate	Powder / 100 pc.	530300
VARIO CU1 F10	0.05 – 5 mg/L Cu	Bicinchoninate	Powder / 1000 pc.	530303
Cyanide Reagent Test 585 nm	0.005 – 0.2 mg/L CN^–	Pyridine-barbituric Acid	1 pc.	2418875
CyA-Test	10 – 160 mg/L CyA	Melamine	Tablet / 100	511370BT
CyA-Test	10 – 160 mg/L CyA	Melamine	Tablet / 250	511371BT
Deionised Water	10 – 160 mg/L CyA	Melamine	250 mL	457022
DEHA Reagent Solution	0.02 – 0.5 mg/L DEHA	PPST	15 mL	461185
DEHA Reagent Solution	0.02 – 0.5 mg/L DEHA	PPST	100 mL	461181
DEHA	0.02 – 0.5 mg/L DEHA	PPST	Tablet / 100	513220BT
DEHA	0.02 – 0.5 mg/L DEHA	PPST	Tablet / 250	513221BT
VARIO DEHA Reagent Set	0.02 – 0.5 mg/L DEHA	PPST	1 pc.	536000
SPADNS Reagent Solution	0.05 – 2 mg/L F^–	SPADNS	250 mL	467481
SPADNS Reagent Solution	0.05 – 2 mg/L F^–	SPADNS	500 mL	467482
Calibration Standard Fluoride	0.05 – 2 mg/L F^–	SPADNS	30 mL	205630
Formaldehyde Spectroquant 1.14678.0001 tube test	1.00 – 5.00 mg/L HCHO	H₂SO₄ / Chromotropic acid	25 pc.	420751
Formaldehyde Spectroquant 1.14500.0001 tube test	0.1 – 5 mg/L HCHO	H₂SO₄ / Chromotropic acid	25 pc.	420752
CALCHECK	50 – 900 mg/L CaCO₃	Murexide	Tablet / 100	515650BT
CALCHECK	50 – 900 mg/L CaCO₃	Murexide	Tablet / 250	515651
CALCHECK	50 – 900 mg/L CaCO₃	Murexide	Tablet / 250	515651BT
Set Calcio H No. 1/No. 2 100 Pc.	20 – 500 mg/L CaCO₃	Murexide	100 each	517761BT
Set Calcio H No. 1/No. 2 250 Pc.	20 – 500 mg/L CaCO₃	Murexide	250 each	517762BT
Hardcheck P	2 – 50 mg/L CaCO₃	Metallphthaleine	Tablet / 100	515660BT
Hardcheck P	2 – 50 mg/L CaCO₃	Metallphthaleine	Tablet / 250	515661BT
Hydrazine Test Powder	0.05 – 0.5 mg/L N₂H₄	Dimethylaminobenzaldehyde	Powder / 30 g	462910
VARIO Hydra 2 Reagent	5 – 600 µg/L N₂H₄	Dimethylaminobenzaldehyde	100 mL	531200
Hydrogen Peroxide LR	0.01 – 0.5 mg/L H₂O₂	DPD / Catalyst	Tablet / 100	512380BT
Hydrogen Peroxide LR	0.01 – 0.5 mg/L H₂O₂	DPD / Catalyst	Tablet / 250	512381BT
Reagent for Hydrogen Peroxide	1 – 50 mg/L H₂O₂	Titanium Tetrachloride / Acid	15 mL	424991
Dilution set sodium hypochlorite	0.2 – 17 % NaOCl	Potassium Iodide	1 pc.	414470
Iron II LR	0.05 – 1 mg/L Fe	Ferrozine / Thioglycolate	Tablet / 100	515420BT
Iron II LR	0.05 – 1 mg/L Fe	Ferrozine / Thioglycolate	Tablet / 250	515421BT
Iron LR	0.05 – 1 mg/L Fe	Ferrozine / Thioglycolate	Tablet / 100	515370BT
Iron LR	0.05 – 1 mg/L Fe	Ferrozine / Thioglycolate	Tablet / 250	515371BT
VARIO Ferro F10	0.02 – 3 mg/L Fe^g)	1,10-Phenanthroline	Powder / 100 pc.	530560
VARIO Ferro F10	0.02 – 3 mg/L Fe^g)	1,10-Phenanthroline	Powder / 1000 pc.	530563
VARIO Fe in MO Reagent Set	0.01 – 1.8 mg/L Fe	TPTZ	1 Set	536010
VARIO Iron TPTZ F10	0.02 – 1.8 mg/L Fe	TPTZ	Powder / 100 pc.	530550
KS135 Pa1/Alk1-Phenolphthalein Sub-Alk P	0.03 – 2 mg/L Fe	Ferrozine / Thioglycolate	65 mL	56L013565
KS144-CH2-FC4-Calcium Hardness Buffer	0.03 – 2 mg/L Fe	Ferrozine / Thioglycolate	65 mL	56L014465
KP962-Ammonium Persulphate Powder	0.03 – 2 mg/L Fe	Ferrozine / Thioglycolate	Powder / 40 g	56P096240
KS63-FE6-Thioglycolate/Molybdate HR RGT	0.03 – 2 mg/L Fe	Ferrozine / Thioglycolate	30 mL	56L006330
KS63-FE6-Thioglycolate/Molybdate HR RGT	0.03 – 2 mg/L Fe	Ferrozine / Thioglycolate	65 mL	56L006365
KS61-FE5-Ferrozin/Thioglycolate	0.03 – 2 mg/L Fe	Ferrozine / Thioglycolate	65 mL	56L006165
Iron LR 2 Reagent Set	0.03 – 2 mg/L Fe	Ferrozine / Thioglycolate	1 pc.	56R023490
KS135 Pa1/Alk1-Phenolphthalein Sub-Alk P	0.03 – 2 mg/L Fe	Ferrozine / Thioglycolate	30 mL	56L013530
KS135 Pa1/Alk1-Phenolphthalein Sub-Alk P	0.03 – 2 mg/L Fe	Ferrozine / Thioglycolate	500 mL	56L013597
KS144-CH2-FC4-Calcium Hardness Buffer	0.03 – 2 mg/L Fe	Ferrozine / Thioglycolate	65 mL	56L014472
KS144-CH2-FC4-Calcium Hardness	0.03 – 2 mg/L Fe	Ferrozine / Thioglycolate	125 mL	56L014491
Iron HR Reagent Set	0.1 – 10 mg/L Fe	Thioglycolate	1 pc.	56R023590
Lead Spectroquant 1.09717.0001 reagent test	0.1 – 5 mg/L Pb	4-(2-Pyridylazo-)-resorcine	25 pc.	420753
Lead Spectroquant 1.14833.0001 tube test	0.1 – 5 mg/L Pb	4-(2-Pyridylazo-)-resorcine	25 pc.	420754
Manganese LR 1	0.2 – 4 mg/L Mn	Formaldoxime	Tablet / 100	516080BT
Manganese LR 1	0.2 – 4 mg/L Mn	Formaldoxime	Tablet / 250	516081BT
Manganese LR 2	0.2 – 4 mg/L Mn	Formaldoxime	Tablet / 100	516090BT
Manganese LR 2	0.2 – 4 mg/L Mn	Formaldoxime	Tablet / 250	516091BT
Set Manganese LR 1/LR 2 100 Pc.	0.2 – 4 mg/L Mn	Formaldoxime	100 each	517621BT
Set Manganese LR 1/LR 2 250 Pc.	0.2 – 4 mg/L Mn	Formaldoxime	250 each	517622BT
VARIO Manganese Reagent, Set Low Range F10	0.01 – 0.7 mg/L Mn	PAN	1 pc.	535090
Vario Rochelle Salt Solution, 30 ml	0.01 – 0.7 mg/L Mn	PAN	30 mL	530640
VARIO Manganese HR, Set High Range F10	0.1 – 18 mg/L Mn	Periodate Oxidation	1 Set	535100
Mangan L, Reagent Set	0.05 – 5 mg/L Mn	Formaldoxime	1 pc.	56R024055
VARIO Molybdenum LR, Set F10	0.03 – 3 mg/L Mo	Ternary Complex	1 pc.	535450
VARIO Molybdenum HR, Set F10	0.3 – 40 mg/L Mo	Mercaptoacetic Acid	1 Set	535300
Molybdate HR No. 1	1 – 50 mg/L MoO₄	Thioglycolate	Tablet / 100	513060BT
Molybdate HR No. 1	1 – 50 mg/L MoO₄	Thioglycolate	Tablet / 250	513061BT
Molybdate HR No. 2	1 – 50 mg/L MoO₄	Thioglycolate	Tablet / 100	513070BT
Molybdate HR No. 2	1 – 50 mg/L MoO₄	Thioglycolate	Tablet / 250	513071BT
Set Molybdate No. 1/No. 2 100 Pc.	1 – 50 mg/L MoO₄	Thioglycolate	100 each	517631BT
Set Molybdate No. 1/No. 2 250 Pc.	1 – 50 mg/L MoO₄	Thioglycolate	250 each	517632BT
Nickel Reagent Test	0.02 – 1 mg/L Ni	Dimethylglyoxime	1 pc.	2419033
Nitrate Test	0.08 – 1 mg/L N	Zinc Reduction / NED	Tablet / 100	502810
Nitrite LR	0.08 – 1 mg/L N	Zinc Reduction / NED	Tablet / 100	512310BT
Nitrite LR	0.08 – 1 mg/L N	Zinc Reduction / NED	Tablet / 250	512311BT
Nitrate Test Pulver	0.08 – 1 mg/L N	Zinc Reduction / NED	Powder / 15 g	465230
Nitrate test tube	0.08 – 1 mg/L N	Zinc Reduction / NED	1 pc.	366220
VARIO Nitra X Reagent, Set	1 – 30 mg/L N	Chromotropic Acid	1 Set	535580
Nitrate-DMP LR2 / 25	0.2 – 15 mg/L N	2,6-Dimethylphenole	25 pc.	2423330
Nitrate-DMP LR / 25	0.5 – 14 mg/L N	2,6-Dimethylphenole	25 pc.	2423340
Nitrate-DMP HR / 25	1.2 – 35 mg/L N	2,6-Dimethylphenole	25 pc.	2423370
Nitrite VHR L, 500 ml	25 – 2500 mg/L NO₂ ^–	Ferrous Sulfate Method	500 mL	471170
Nitrite VHR L, 500 ml, Set	25 – 2500 mg/L NO₂ ^–	Ferrous Sulfate Method	500 mL	471160
VARIO Nitri 3 F10	0.01 – 0.3 mg/L N	Diazotation	Powder / 100 pc.	530980
VARIO Nitri NT-2 F10	2 – 250 mg/L NO₂ ^–	Ferrous Sulfate Method	Powder / 100 pc.	530280
Nitrite LR / 25	0.03 – 0.6 mg/L N	Sulfanilic / Naphthylamine	1 pc.	2423420
Nitrite / 25	0.03 – 0.6 mg/L N	Sulfanilic / Naphthylamine	1 pc.	2419018
Nitrite HR / 25	0.3 – 3 mg/L N	Sulfanilic / Naphthylamine	1 pc.	2423470
VARIO Total Nitrogen LR, Set	0.5 – 25 mg/L N^b)	Persulphate Digestion	1 Set	535550
VARIO Total Nitrogen HR, Set	5 – 150 mg/L N^b)	Persulphate Digestion	1 Set	535560
Total Nitrogen DMP LR / 25	0.5 – 14 mg/L N^b)	2,6-Dimethylphenole	1 pc.	2423540
Total Nitrogen	0.5 – 14 mg/L N^b)	2,6-Dimethylphenole	1 pc.	2420703
Total Nitrogen DMP HR / 25	5 – 140 mg/L N^{b) i)}	2,6-Dimethylphenole	1 pc.	2423570
Vacu-vial Oxygen Test Kit	10 – 1100 µg/L O₂ ^c)	Rhodazine D TM	1 Set	380450
Phenole No. 1	0.1 – 5 mg/L C₆H₅OH	4-Aminoantipyrine	Tablet / 100	515950BT
Phenole No. 2	0.1 – 5 mg/L C₆H₅OH	4-Aminoantipyrine	Tablet / 100	515960BT
Phosphonate Set	0.02 – 125 mg/L PO₄	Persulfate UV Oxidation Method	1 Set	535220
Phosphate-total LR/24	0.07 – 3 mg/L P^b)	Phosphomolybdenum Blue	24 pc.	2419019
Phosphate-total HR/24	1.5 – 20 mg/L P^b)	Phosphomolybdenum Blue	24 pc.	2420700
Phosphate No. 1 LR	0.016 – 1.305 mg/L P	Phosphomolybdenum Blue	Tablet / 100	513040BT
Phosphate No. 2 LR	0.016 – 1.305 mg/L P	Phosphomolybdenum Blue	Tablet / 100	513050BT
Phosphate No. 2 LR	0.016 – 1.305 mg/L P	Phosphomolybdenum Blue	Tablet / 250	513051BT
Set Phosphate No. 1 LR/No. 2 LR 100 Pc.	0.016 – 1.305 mg/L P	Phosphomolybdenum Blue	100 each	517651BT
Set Phosphate No. 1 HR/No. 2 HR 100 Pc.	0.33 – 26.09 mg/L P	Vanadomolybdate	100 each	517661BT
Phosphate HR P1	0.33 – 26.09 mg/L P	Vanadomolybdate	Tablet / 100	515810BT
Phosphate HR P2	0.33 – 26.09 mg/L P	Vanadomolybdate	Tablet / 100	515820BT
Phosphate-ortho/24	0.98 – 19.57 mg/L P	Vanadomolybdate	24 pc.	2420701
VARIO PHOS 3 F10	0.02 – 0.815 mg/L P	Phosphomolybdenum Blue	Powder / 100 pc.	531550
VARIO Phosphate-Ortho, Set	0.02 – 1.63 mg/L P	Phosphomolybdenum Blue	1 Set	535200
VARIO Phosphate, acid hydrolyzable, Total Set	0.02 – 1.6 mg/L P^b)	Phosphomolybdenum Blue	1 Set	535250
VARIO Phosphate, Total Set	0.02 – 1.1 mg/L P^b)	Phosphomolybdenum Blue	1 Set	535210
Vacu-vial Phosphate Test Kit	1.6 – 13 mg/L P^c)	Vanadomolybdate	1 Set	380460
Vacu-vial Phosphate Test Kit	0.016 – 1.6 mg/L P^c)	Stannous Chloride	1 Set	380480
Phosphate LR Reagent Pack	0.1 – 10 mg/L PO₄	Phosphomolybic Acid / Ascorbic Acid	1 pc.	56R023765
KS278-Sulphuric Acid 50 % V/V	0.1 – 10 mg/L PO₄	Phosphomolybic Acid / Ascorbic Acid	65 mL	56L027865
Phosphat HR, Ortho Reagent Set	5 – 80 mg/L PO₄	Vanadomolybdate	1 pc.	56R019090
Bromocresol Purple Photometer	5.2 – 6.8 pH	Bromocresolpurple	Tablet / 100	515700BT
Bromocresol Purple Photometer	5.2 – 6.8 pH	Bromocresolpurple	Tablet / 250	515701BT
Phenol Red Photometer	6.5 – 8.4 pH	Phenol Red	Tablet / 100	511770BT
Phenol Red Photometer	6.5 – 8.4 pH	Phenol Red	Tablet / 250	511771BT
Phenol Red Photometer	6.5 – 8.4 pH	Phenol Red	Tablet / 500	511772BT
Phenol Red Solution	6.5 – 8.4 pH	Phenol Red	15 mL	471040
Phenol Red Solution	6.5 – 8.4 pH	Phenol Red	100 mL	471041
Phenol Red Solution in 6-pack	6.5 – 8.4 pH	Phenol Red	1 pc.	471046
Thymol Blue Photometer	8.0 – 9.6 pH	Thymol Blue	Tablet / 100	515710BT
Thymol Blue Photometer	8.0 – 9.6 pH	Thymol Blue	Tablet / 250	515711BT
Polyacrylat Reagent Set	1 – 30 mg/L Polyacryl	Turbidity	1 pc.	56R019165
KS173-P2-2,4 Dinitrophenol Indicator	1 – 30 mg/L Polyacryl	Turbidity	65 mL	56L017365
KS183-QA2-MO1-P3-Nitric Acid	1 – 30 mg/L Polyacryl	Turbidity	65 mL	56L018365
Potassium-T	0.7 – 16 mg/L K	Tetraphenylborat Turbidity	Tablet / 100	515670BT
Potassium-T	0.7 – 16 mg/L K	Tetraphenylborat Turbidity	Tablet / 250	515671BT
Silica No. 1	0.05 – 4 mg/L SiO₂	Silicomolybdenum Blue	Tablet / 100	513130BT
Silica No. 1	0.05 – 4 mg/L SiO₂	Silicomolybdenum Blue	Tablet / 250	513131BT
Silica No. 2	0.05 – 4 mg/L SiO₂	Silicomolybdenum Blue	Tablet / 100	513140BT
Silica No. 2	0.05 – 4 mg/L SiO₂	Silicomolybdenum Blue	Tablet / 250	513141BT
Silica PR	0.05 – 4 mg/L SiO₂	Silicomolybdenum Blue	Tablet / 100	513150BT
Silica PR	0.05 – 4 mg/L SiO₂	Silicomolybdenum Blue	Tablet / 250	513151BT
Set Silica No. 1/No. 2 100 Pc.	0.05 – 4 mg/L SiO₂	Silicomolybdenum Blue	100 each	517671BT
Set Silica No. 1/No. 2 250 Pc.	0.05 – 4 mg/L SiO₂	Silicomolybdenum Blue	250 each	517672BT
VARIO Silica LR, Set F10	0.05 – 1.6 mg/L SiO₂	Heteropolyblue	1 Set	535690
VARIO Silica HR Reagent, Set F10	1 – 100 mg/L SiO₂	Silicomolybdate	1 Set	535700
Silica LR L	0.1 – 8 mg/L SiO₂	Heteropolyblue	1 Set	56R023856
Silicate VLR PP Reagent Set	0.005 – 0.5 mg/L SiO₂	Heteropolyblue	1 Set	5443002
Sulfate Turbidity	5 – 100 mg/L SO₄ ^2-	Bariumsulphate Turbidity	Tablet / 100	515450BT
Sulfate Turbidity	5 – 100 mg/L SO₄ ^2-	Bariumsulphate Turbidity	Tablet / 250	515451BT
VARIO Sulfa 4 F10	5 – 100 mg/L SO₄ ^2-	Bariumsulphate Turbidity	Powder / 100 pc.	532160
Sulfide No. 1	0.04 – 0.5 mg/L S^2-	DPD / Catalyst	Tablet / 100	502930
Sulfide No. 2	0.04 – 0.5 mg/L S^2-	DPD / Catalyst	Tablet / 100	502940
Sulfite LR	0.1 – 12 mg/L SO₃	DTNB	Tablet / 100	518020BT
Surfactants (anionic) Spectroquant 1.02552.0001 tube test	0.05 – 2 mg/L SDSA	Methylene Blue	25 pc.	420763
Surfactants (non ionic) Spectroquant 1.01787.0001 tube test	0.1 – 7.5 mg/L Triton X-100	TBPE	25 pc.	420764
Surfactants (cationic) Spectroquant 1.01764.0001 tube test	0.05 – 1.5 mg/L CTAB	Disulphine Blue	25 pc.	420765
TOC Spectroquant 1.14878.0001 tube test	5 – 80 mg/L TOC^b)	H₂SO₄ / Persulphate / Indicator	25 pc.	420761
TOC Spectroquant 1.14879.0001 tube test	50 – 800 mg/L TOC^b)	H₂SO₄ / Persulphate / Indicator	25 pc.	420756
VARIO Triazole Rgt Powder Pack F25	1 – 16 mg/L Benzotriazole or Tolyltriazole	Catalyzed UV Digestion	Powder / 100 pc.	532200
UREA Reagent 1	0.1 – 2.5 mg/L Urea	Indophenol / Urease	15 mL	459300
UREA Reagent 2	0.1 – 2.5 mg/L Urea	Indophenol / Urease	10 mL	459400
Urea Pretreat	0.1 – 2.5 mg/L Urea	Indophenol / Urease	Tablet / 100	516110BT
UREA Reagent Set	0.1 – 2.5 mg/L Urea	Indophenol / Urease	1 Set	517800BT
Copperr/Zinc LR	0.02 – 1 mg/L Zn	Zincon	Tablet / 100	512620BT
Copperr/Zinc LR	0.02 – 1 mg/L Zn	Zincon	Tablet / 250	512621BT
EDTA	0.02 – 1 mg/L Zn	Zincon	Tablet / 100	512390BT
EDTA	0.02 – 1 mg/L Zn	Zincon	Tablet / 250	512391BT
Dechlor	0.02 – 1 mg/L Zn	Zincon	Tablet / 100	512350BT
Zinc Reagent 1/Zinc Reagent 2	0.1 – 2.5 mg/L Zn	Zincon / EDTA	1 pc.	56R023965
KS 89 – Cationic Suppressor	0.1 – 2.5 mg/L Zn	Zincon / EDTA	65 mL	56L008965

Accessories

Title	Part Number	Add to quotation cart
ValidCheck Chlorine 1,5 mg/l	48105510
Thermoreactor RD 125	2418940
Stirring rod and spoon	56A006601
Semimicro cell, 50 mm with lid	71310045
Measuring spoon, 1 g	384930
Adapter (13 mm) MultiDirect for Vacu-vial	192075
Adapter for round cuvettes 13 mm	19802192
Round cuvette 16 mm, set of 10	197665
Mixing cylinder, 25 ml	19802650
Measuring spoon no. 8, black	424513
Plastic funnel with handle (white)	471007
Pipette, 1000 µl	365045
Pipette tips, 0,1-1 ml (white), 1000 pc.	419073
UV Pen Lamp, 254 nm	400740
W100/OG/50MM Rectangular cell, optical glass	601070
Universal Container – Cap	424648
Round cuvette 24 mm, set of 5	197629
Automatic pipette, 1-5 ml	419076
Pipette tips, 1-5 ml (white) 100 pc.	419066
Screw caps TOC	420757
Inspection and calibration package for XD7000	19802707
Light source replacement XD 7000	71310000
Carrying case for XD 7000/7500	71310010
12 V-plug connector for XD 7000/7500	71310020
Batteries (AA), set of 4	1950025
Energy station XD series/SpectroDirect	711051
USB cable 3 m	2444482
Barcode Hand-held Scanner	71310030
Cleaning cloth	197635
Round cuvette 24 mm, set of 12	197620
Zero cuvette ø 16 mm for XD 7000/7500	215661
Zero cuvette ø 24 mm for XD 7000/7500	215662
Cuvette stand for 6 round cuvettes Ø 24 mm	418951
Cuvette stand for 10 round cuvettes Ø 16 mm	418957
W100/OG/10MM Rectangular cell, optical glass	601040
W100/OG/20MM Rectangular cell, optical glass for determination of arsenic	601050
W110/UV/10MM Rectangular cell, Quartz UV	661130
W110/UV/20MM Rectangular cell, Quartz UV	661140
W110/UV/50MM Rectangular cell, Quartz UV	661160
Secondary standard set VIS with DAkkS calibration certificate	711160
Automatic pipette, 0,1-1 ml	419077
Factory calibration certificate ISO 9001 for XD7000	999754

Downloads

Title	Online Download Type	Format
Datasheet 71307000 – Spectrophotometer XD 7000 (VIS)	Datasheet	PDF (0.20 MB)
Instruction Manual XD 7000	Instruction Manual	PDF (3.60 MB)
New Methods – XD series – 11_2021	Instruction Manual	ZIP (3.39 MB)
Quick Start Guide XD 7000	Instruction Manual	PDF (4.10 MB)
Quick Start Guide XD 7000	Instruction Manual	PDF (3.88 MB)
Quick Start Guide XD 7000	Instruction Manual	PDF (3.45 MB)
Instruction Manual Single Method M100 – Chlorine T	Procedure Single Method	PDF (0.76 MB)
Instruction Manual Single Method M101 – Chlorine L	Procedure Single Method	PDF (0.74 MB)
Instruction Manual Single Method M104 – Chlorine HR 10 T	Procedure Single Method	PDF (0.70 MB)
Instruction Manual Single Method M105 – Chlorine HR (KI) T (105)	Procedure Single Method	PDF (0.61 MB)
Instruction Manual Single Method M110 – Chlorine PP	Procedure Single Method	PDF (0.73 MB)
Instruction Manual Single Method M113 – Chlorine MR PP	Procedure Single Method	PDF (0.73 MB)
Instruction Manual Single Method M119 – Chlorine dioxide 50 T	Procedure Single Method	PDF (0.60 MB)
Instruction Manual Single Method M120 – Chlorine dioxide T	Procedure Single Method	PDF (0.80 MB)
Instruction Manual Single Method M122 – Chlorine dioxide PP	Procedure Single Method	PDF (0.72 MB)
Instruction Manual Single Method M124 – Chromium 50 PP	Procedure Single Method	PDF (0.81 MB)
Instruction Manual Single Method M125 – Chromium PP	Procedure Single Method	PDF (0.74 MB)
Instruction Manual Single Method M130 – COD LR TT	Procedure Single Method	PDF (0.80 MB)
Instruction Manual Single Method M131 – COD MR TT	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M132 – COD HR TT	Procedure Single Method	PDF (0.68 MB)
Instruction Manual Single Method M133 – COD LMR TT	Procedure Single Method	PDF (0.68 MB)
Instruction Manual Single Method M134 – COD VLR TT	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M149 – Copper 50 T	Procedure Single Method	PDF (0.64 MB)
Instruction Manual Single Method M150 – Copper T	Procedure Single Method	PDF (0.77 MB)
Instruction Manual Single Method M151 – Copper L	Procedure Single Method	PDF (0.82 MB)
Instruction Manual Single Method M153 – Copper PP	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M156 – Cyanide 50 L	Procedure Single Method	PDF (0.62 MB)
Instruction Manual Single Method M157 – Cyanide L	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M160 – CyA T	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M165 – DEHA T (L)	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M167 – DEHA PP	Procedure Single Method	PDF (0.75 MB)
Instruction Manual Single Method M170 – Fluoride L	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M175 – Formaldehyde 10 M. L	Procedure Single Method	PDF (0.74 MB)
Instruction Manual Single Method M176 – Formaldehyde 50 M. L	Procedure Single Method	PDF (0.71 MB)
Instruction Manual Single Method M177 – Formaldehyde M. TT	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M190 – Hardness Calcium (B) T	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M191 – Hardness Calcium (B) T	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M20 – K_S4.3 T	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M200 – Hardness total T	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M201 – Hardness total HR T	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M203 – Hazen 50	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M204 – Hazen 24	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M205 – Hydrazine P	Procedure Single Method	PDF (0.64 MB)
Instruction Manual Single Method M206 – Hydrazine L	Procedure Single Method	PDF (0.72 MB)
Instruction Manual Single Method M207 – Hydrazine C	Procedure Single Method	PDF (0.61 MB)
Instruction Manual Single Method M209 – H₂O₂ 50 T	Procedure Single Method	PDF (0.62 MB)
Instruction Manual Single Method M210 – H₂O₂ T	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M212 – Hypochlorite T	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M213 – H₂O₂ LR L	Procedure Single Method	PDF (0.61 MB)
Instruction Manual Single Method M214 – H₂O₂ HR L	Procedure Single Method	PDF (0.61 MB)
Instruction Manual Single Method M215 – lodine T	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M218 – Iron 10 T	Procedure Single Method	PDF (0.69 MB)
Instruction Manual Single Method M219 – Iron 50 T	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M220 – Iron T	Procedure Single Method	PDF (0.70 MB)
Instruction Manual Single Method M221 – Iron 50 PP	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M222 – Iron PP	Procedure Single Method	PDF (0.70 MB)
Instruction Manual Single Method M223 – Iron (TPTZ) PP	Procedure Single Method	PDF (0.76 MB)
Instruction Manual Single Method M224 – Iron in Mo PP (224)	Procedure Single Method	PDF (0.70 MB)
Instruction Manual Single Method M225 – Iron LR L (A)	Procedure Single Method	PDF (0.76 MB)
Instruction Manual Single Method M226 – Iron LR L (B)	Procedure Single Method	PDF (0.82 MB)
Instruction Manual Single Method M227 – Iron HR L	Procedure Single Method	PDF (0.78 MB)
Instruction Manual Single Method M232 – Lead 10	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M234 – Lead (A) TT	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M235 – Lead (B) TT	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M240 – Manganese T	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M242 – Manganese LR PP	Procedure Single Method	PDF (0.75 MB)
Instruction Manual Single Method M243 – Manganese HR PP	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M245 – Manganese L	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M250 – Molybdate T	Procedure Single Method	PDF (0.64 MB)
Instruction Manual Single Method M251 – Molybdate LR PP	Procedure Single Method	PDF (0.70 MB)
Instruction Manual Single Method M252 – Molybdate HR PP	Procedure Single Method	PDF (0.68 MB)
Instruction Manual Single Method M254 – Molybdate HR L	Procedure Single Method	PDF (0.64 MB)
Instruction Manual Single Method M255 – Nickel 50 L	Procedure Single Method	PDF (0.62 MB)
Instruction Manual Single Method M256 – Nickel L	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M260 – Nitrate T	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M265 – Nitrate TT	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M266 – Nitrate LR2 TT	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M267 – Nitrate LR TT	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M268 – Nitrate HR	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M270 – Nitrite T	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M271 – Nitrite VHR L	Procedure Single Method	PDF (0.61 MB)
Instruction Manual Single Method M272 – Nitrite PP	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M273 – Nitrite HR PP	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M275 – Nitrite LR TT	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M276 – Nitrite HR TT	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M280 – TN LR TT	Procedure Single Method	PDF (0.79 MB)
Instruction Manual Single Method M281 – TN HR TT	Procedure Single Method	PDF (0.79 MB)
Instruction Manual Single Method M283 – TN LR 2 TT	Procedure Single Method	PDF (0.71 MB)
Instruction Manual Single Method M284 – TN HR 2 TT	Procedure Single Method	PDF (0.71 MB)
Instruction Manual Single Method M290 – Oxygen active T	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M292 – Oxygen dissolved C	Procedure Single Method	PDF (0.61 MB)
Instruction Manual Single Method M299 – Ozone 50 T	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M30 – Alkalinity-m T	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M300 – Ozone T	Procedure Single Method	PDF (0.77 MB)
Instruction Manual Single Method M301 – Ozone PP	Procedure Single Method	PDF (0.74 MB)
Instruction Manual Single Method M31 – Alkalinity-m HR T	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M315 – Phenol T	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M316 – Phosphonate PP	Procedure Single Method	PDF (0.77 MB)
Instruction Manual Single Method M317 – Phosphate total LR TT	Procedure Single Method	PDF (0.71 MB)
Instruction Manual Single Method M318 – Phosphate total HR TT	Procedure Single Method	PDF (0.70 MB)
Instruction Manual Single Method M320 – Phosphate LR T	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M321 – Phosphate HR T	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M322 – Phosphate HR TT	Procedure Single Method	PDF (0.62 MB)
Instruction Manual Single Method M323 – Phosphate PP	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M324 – Phosphate TT	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M325 – Phosphate h. TT	Procedure Single Method	PDF (0.70 MB)
Instruction Manual Single Method M326 – Phosphate t. TT	Procedure Single Method	PDF (0.70 MB)
Instruction Manual Single Method M327 – Phosphate HR C	Procedure Single Method	PDF (0.60 MB)
Instruction Manual Single Method M328 – Phosphate LR C	Procedure Single Method	PDF (0.62 MB)
Instruction Manual Single Method M329 – pH-value LR T	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M330 – pH-value T	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M331 – pH value L	Procedure Single Method	PDF (0.61 MB)
Instruction Manual Single Method M332 – pH-value HR T	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M334 – Phosphate LR L	Procedure Single Method	PDF (0.72 MB)
Instruction Manual Single Method M335 – Phosphate HR L	Procedure Single Method	PDF (0.72 MB)
Instruction Manual Single Method M338 – Polyacrylate L	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M340 – Potassium T	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M345 – SAC 436 nm	Procedure Single Method	PDF (0.62 MB)
Instruction Manual Single Method M346 – SAC 525 nm	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M347 – SAC 620 nm	Procedure Single Method	PDF (0.62 MB)
Instruction Manual Single Method M349 – Silica VLR PP	Procedure Single Method	PDF (0.68 MB)
Instruction Manual Single Method M35 – Alkalinity-p T	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M350 – Silcate T	Procedure Single Method	PDF (0.69 MB)
Instruction Manual Single Method M351 – Silicate LR PP	Procedure Single Method	PDF (0.80 MB)
Instruction Manual Single Method M352 – Silicate HR PP	Procedure Single Method	PDF (0.70 MB)
Instruction Manual Single Method M353 – Silicate L	Procedure Single Method	PDF (0.69 MB)
Instruction Manual Single Method M355 – Sulphate T	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M360 – Sulphate PP	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M361 – Sulphate HR PP	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M363 – Selenium	Procedure Single Method	PDF (0.06 MB)
Instruction Manual Single Method M365 – Sulphide T	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M368 – Sulphite 10 T	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M370 – Sulphite T	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M376 – Surfactants M. (anion.) TT	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M377 – Surfactants M. (not ionic) TT	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M378 – Surfactants M. (cation.) TT	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M380 – TOC LR M. TT	Procedure Single Method	PDF (0.64 MB)
Instruction Manual Single Method M381 – TOC HR M. TT	Procedure Single Method	PDF (0.64 MB)
Instruction Manual Single Method M383 – Suspended solids 50	Procedure Single Method	PDF (0.62 MB)
Instruction Manual Single Method M384 – Suspended solids 24	Procedure Single Method	PDF (0.64 MB)
Instruction Manual Single Method M385 – Turbidity 50	Procedure Single Method	PDF (0.62 MB)
Instruction Manual Single Method M386 – Turbidity 24	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M388 – Triazole PP	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M390 – Urea T	Procedure Single Method	PDF (0.72 MB)
Instruction Manual Single Method M40 – Aluminium T	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M400 – Zinc T	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M405 – Zinc L	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M50 – Aluminium PP	Procedure Single Method	PDF (0.72 MB)
Instruction Manual Single Method M60 – Ammonia T	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M62 – Ammonia PP	Procedure Single Method	PDF (0.74 MB)
Instruction Manual Single Method M65 – Ammonia LR TT	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M66 – Ammonia HR TT	Procedure Single Method	PDF (0.67 MB)
Instruction Manual Single Method M68 – Arsenic	Procedure Single Method	PDF (0.61 MB)
Instruction Manual Single Method M70 – PHMB T	Procedure Single Method	PDF (0.64 MB)
Instruction Manual Single Method M78 – Bromine 10 T	Procedure Single Method	PDF (0.63 MB)
Instruction Manual Single Method M79 – Bromine 50 T	Procedure Single Method	PDF (0.61 MB)
Instruction Manual Single Method M80 – Bromine T	Procedure Single Method	PDF (0.64 MB)
Instruction Manual Single Method M81 – Bromine PP	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M85 – Boron T	Procedure Single Method	PDF (0.66 MB)
Instruction Manual Single Method M87 – Cadmium M. TT	Procedure Single Method	PDF (0.70 MB)
Instruction Manual Single Method M90 – Chloride T	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M91 – Chloride L (A)	Procedure Single Method	PDF (0.74 MB)
Instruction Manual Single Method M91 – Chloride L (A)	Procedure Single Method	PDF (0.74 MB)
Instruction Manual Single Method M92 – Chloride L (B)	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M92 – Chloride L (B)	Procedure Single Method	PDF (0.65 MB)
Instruction Manual Single Method M98 – Chlorine 10 T	Procedure Single Method	PDF (0.71 MB)
Instruction Manual Single Method M99 – Chlorine 50 T	Procedure Single Method	PDF (0.69 MB)
Firmware XD Series	Firmware	ZIP (1.53 MB)
Tintometer Chlorine Comparability Study	Studies	PDF (0.91 MB)
EU-Declaration of Conformity XD 7000 / XD 7500	Declaration of Conformity	PDF (0.19 MB)
Validation Data COD High Range	Validation Data	PDF (0.12 MB)
Validation Data COD High Range, Mercury free	Validation Data	PDF (0.06 MB)
Validation Data COD Low Range	Validation Data	PDF (0.12 MB)
Validation Data COD Low Range, Mercury free	Validation Data	PDF (0.06 MB)
Validation Data COD Mid Range	Validation Data	PDF (0.11 MB)
Validation Data COD Mid Range, Mercury free	Validation Data	PDF (0.06 MB)
Validation Data DPD No.1 Free Chlorine	Validation Data	PDF (0.12 MB)
Validation Data Free Chlorine DPD F10	Validation Data	PDF (0.12 MB)
Validation Data Total Chlorine DPD F10	Validation Data	PDF (0.12 MB)
Validation Data VARIO Free Chlorine F10 Powder Pack	Validation Data	PDF (0.11 MB)
Validation Data VARIO Total Chlorine F10 Powder Pack	Validation Data	PDF (0.12 MB)
Validation Data VARIO Total Nitrogen HR	Validation Data	PDF (0.12 MB)
Validation Data VARIO Total Nitrogen LR	Validation Data	PDF (0.12 MB)

Delivery Content

4 batteries (AA)
1 power supply cable
4 round cuvettes with lid and 1 zero cuvette XD 7×00 (ø 24 mm)
1 zero cuvette (ø 16 mm)
Quickstart guide in 24 languages
Full user manual in 8 languages

Spectrophotometer XD 7000 VIS
